Product Description
AMD Ryzen 7 7735HS. 8-Core 16-Thread. 4.9GHz. LPDDR5. Triple 4K 60Hz. 2.5G LAN. 470g. 0.61L.
The Firebat A6 is a high-performance mini PC built around the AMD Ryzen 7 7735HS - an 8-core, 16-thread Zen 3+ processor with up to 4.9GHz turbo boost and three switchable performance modes. Unlike U-class mobile chips, the HS-class 7735HS is a higher-TDP processor that delivers sustained performance closer to a full desktop workstation than a typical mini PC. 16GB dual-channel LPDDR5 RAM (soldered - not upgradeable). Ships with 512GB SSD plus a reserved M.2 2280 slot for storage expansion. Supports up to three independent 4K 60Hz displays simultaneously via HDMI, DisplayPort, and USB-C. 2.5G Ethernet for fast wired networking. Wi-Fi 6, Bluetooth 5.2. Six USB-A ports plus USB-C with display output. 0.61-liter body, 470g. VESA mount included. Windows 11 pre-installed. CE + FCC certified. Ships from United States.
Important: The RAM is LPDDR5 soldered permanently to the motherboard. It cannot be removed, replaced, or upgraded. Select your configuration carefully.
Key Features
- AMD Ryzen 7 7735HS - 8-core, 16-thread, Zen 3+, up to 4.9GHz turbo - The HS designation means this is a higher-TDP (35-45W configurable) processor designed for sustained performance under load, unlike U-class chips (15-28W) found in typical mini PCs; 8 cores and 16 threads on the Zen 3+ architecture; 4.9GHz single-core turbo; three switchable performance modes to balance performance and thermals; AMD Radeon 680M integrated graphics (12 RDNA2 compute units) - the most capable integrated GPU in the Zen 3+ lineup
- AMD Ryzen 7 6800HS option - Previous-generation 8-core Zen 3+ processor; also HS-class with strong sustained performance; same core count and thread count as the 7735HS with slightly lower clock ceiling; ideal for buyers who want HS-class performance at a lower price point
- 16GB dual-channel LPDDR5 (soldered - not upgradeable) - LPDDR5 provides higher memory bandwidth than LPDDR4 or DDR4, benefiting both CPU and AMD Radeon 680M GPU tasks; dual-channel configuration maximizes throughput; permanently soldered to the motherboard - cannot be upgraded after purchase
- 512GB SSD + reserved M.2 2280 expansion slot - Ships with 512GB SSD; empty M.2 2280 slot available for user storage expansion with a standard SATA or NVMe M.2 drive; no reinstallation needed - new drive mounts as an additional volume
- Triple 4K 60Hz independent display support - Connect up to three monitors simultaneously: HDMI 2.0 (4K@60Hz) + DisplayPort 1.4 (4K@60Hz) + USB-C with display output (4K@60Hz); run three independent desktops for multi-screen workflows, trading stations, surveillance, or content production
- 2.5G Ethernet (2500Mbps) - 2.5x faster than standard Gigabit Ethernet; benefits NAS transfers, large file workflows, and high-throughput network environments; requires a 2.5G-compatible router or switch for full speed; backward-compatible with 1G networks
- Wi-Fi 6 (802.11ax) + Bluetooth 5.2 - Wi-Fi 6 for fast wireless; BT 5.2 for wireless peripherals; M.2 2230 network card is user-replaceable for future wireless upgrades
- 6x USB-A + 1x USB-C with display output - Six USB-A ports for all peripherals; USB-C supports display output plus data; no docking station needed
- 0.61-liter body - 470g - Among the most compact HS-class mini PCs available; VESA mount included for behind-monitor installation
- Advanced cooling - low-noise sustained operation - Engineered for continuous HS-class workloads; quiet under sustained load
- Windows 11 pre-installed
- In the box: Firebat A6, HDMI cable, US power adapter, VESA mount
- CE + FCC certified | Ships from United States
Firebat A6 vs Firebat R3 - Key Differences
- Processor class: A6 uses HS-class (higher TDP, sustained performance) vs R3 U-class (efficiency-focused)
- GPU: A6 Radeon 680M (12 CU RDNA2) vs R3 standard Radeon integrated; 680M is significantly stronger for gaming and GPU-accelerated workloads
- Memory: A6 LPDDR5 dual-channel vs R3 LPDDR4; higher bandwidth benefits CPU and GPU
- Network: A6 has 2.5G Ethernet vs R3 1G Ethernet
- Displays: A6 supports 3 independent 4K displays vs R3 2
- Size/Weight: A6 is 0.61L / 470g; R3 is 1.05kg
Specifications
- Brand: Firebat | Model: A6
- Processor: AMD Ryzen 7 7735HS (8C/16T, Zen 3+, up to 4.9GHz) | AMD Ryzen 7 6800HS (8C/16T, Zen 3+)
- GPU: AMD Radeon 680M (12 CU RDNA2) - integrated
- RAM: 16GB dual-channel LPDDR5, soldered (not upgradeable)
- Storage: 512GB SSD + 1x reserved M.2 2280 slot
- Display Output: HDMI 2.0 + DisplayPort 1.4 + USB-C (triple 4K@60Hz)
- LAN: 2.5G Ethernet (2500Mbps)
- Wi-Fi: Wi-Fi 6 (802.11ax), M.2 2230 upgradeable
- Bluetooth: 5.2
- USB: 6x USB-A + 1x USB-C (display output)
- Audio: 3.5mm combo jack
- OS: Windows 11
- Volume: 0.61L | Weight: 470g
- Certification: CE, FCC
- In the Box: A6 Mini PC, HDMI cable, US power adapter, VESA mount
- Ships From: United States
Frequently Asked Questions
What makes the Ryzen 7 7735HS different from U-class Ryzen processors in other mini PCs?
The HS suffix indicates a higher-TDP processor configured for 35-45W sustained power draw, compared to U-class processors (such as the Ryzen 7 7730U in the Firebat R3) which run at 15-28W. In practice, the 7735HS sustains higher clock speeds under continuous load without throttling as aggressively as a U-class chip. For workloads that push the CPU continuously - video encoding, 3D rendering, large data processing, virtual machines, compiling code - the HS chip maintains performance closer to its peak specifications for longer. U-class processors are optimized for efficiency and better suited for light-to-moderate workloads. The A6's HS processor comes with a more sophisticated cooling system to handle the higher thermal output. Choose the A6 if sustained heavy CPU workloads are your primary use case.
Can this mini PC run three monitors simultaneously and what cables do I need?
Yes - the Firebat A6 supports up to three independent 4K 60Hz displays simultaneously. The three video outputs are: HDMI 2.0 (standard HDMI cable - one included), DisplayPort 1.4 (DisplayPort cable or DP-to-HDMI adapter, not included), and USB-C with display output (USB-C to DisplayPort cable or USB-C to HDMI adapter, not included). All three displays run as fully independent desktops in extended mode - not mirrored. Configure in Windows Display Settings (right-click desktop, Display settings). For triple-monitor setups, a multi-monitor arm or three individual stands are needed.
What is 2.5G Ethernet and do I need a special router to use it?
2.5G Ethernet supports speeds up to 2500Mbps - 2.5 times faster than standard Gigabit Ethernet (1000Mbps). To achieve full 2.5Gbps speeds, your router, switch, or NAS must also have a 2.5G port. If your current router has only 1G ports, the A6 negotiates down to 1Gbps - no speed advantage, but the connection works normally. 2.5G Ethernet is most beneficial for large file transfers to a 2.5G NAS, internet connections above 1Gbps, and high-throughput local network workflows. The port is fully backward-compatible with all standard 1G and 100Mbps networks.
Can the RAM or storage be upgraded after purchase?
Storage: yes - the reserved M.2 2280 slot is empty and user-accessible for a standard SATA or NVMe M.2 SSD. The new drive appears as an additional volume in Windows Disk Management without reinstalling Windows. RAM: no - the 16GB LPDDR5 is permanently soldered to the motherboard and cannot be removed, upgraded, or replaced without risking irreversible board damage. This is a fundamental hardware design characteristic, not a warranty restriction. If 16GB is insufficient for your workloads, this product is not the right fit.
How does the AMD Radeon 680M handle gaming compared to Intel integrated graphics?
The AMD Radeon 680M (12 compute units, RDNA2) is consistently among the best integrated GPUs in any mini PC, significantly outperforming Intel Iris Xe and UHD graphics. It can run many popular titles at 1080p medium settings: League of Legends, CS2, Rocket League, and older AAA games at playable frame rates. More demanding modern titles will require lower resolution and minimum settings. The 680M benefits heavily from dual-channel memory bandwidth - the A6's LPDDR5 dual-channel configuration maximizes GPU throughput. It is not a substitute for a dedicated GPU, but for integrated graphics gaming it is the strongest available in a mini PC today.
What is the VESA mount and how do I install it?
The included VESA mount bracket attaches to the rear of the A6 and mounts it to any VESA-compatible monitor or TV using the standard 75x75mm or 100x100mm VESA mounting holes. Installation: attach the bracket to the A6 with the included screws, then fasten the bracket to your monitor's VESA holes. At 470g, the A6 is light enough for any monitor arm. Once mounted, the A6 sits hidden behind your display with all cables routing from the rear, eliminating desk footprint entirely and creating a clean all-in-one appearance.
