Product Description
Fast and comfortable
Our Active geometry puts you in a slightly more forward position to give you more pedalling efficiency while staying comfortable on long rides.
All-Road capable
Wide 42c Girona tires offer traction and control on paved or unpaved paths.
Reliable and durable
The Shimano CUES drivetrain offers a hassle-free, low-maintenance performance riders can rely on for the long haul. CUES features Shimano’s new LINKGLIDE drivetrain technology for less wear and tear on chains, cassettes, and chainrings.
A better way to produce aluminum
Starting in 2024, we began removing high-emission aluminum from our manufacturing and replacing it with low-emission aluminum made with renewable energy. By October 2025, nearly every alloy bike we make - this one included - had made the switch, driving a major drop in our footprint.
Upgrade your pedals and love your bike more
Pedals are two of the five touchpoints that connect you with your bike, and even though this bike comes with a pair, upgrading to pedals that boost control and grip will greatly improve your ride. See the pedal guide and find the best pedals for your riding style. We recommend flat pedals for simple versatility.
| Frame | Alpha Gold Aluminum, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR |
| Fork | Dual Sport carbon, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR |
| Tire | Bontrager Girona Comp, wire bead, 60 tpi, 700x42mm |
| Hub Front | Formula DC-20, alloy, 6-bolt, 100x5mm |
| Hub Rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm |
| Rim | Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve |
| Skewer Front | 139x5mm bolt-on |
| Skewer Rear | 152x5mm QR |
| Shifter | Shimano CUES U6000 w/optical gear display, 10 speed |
| Rear Derailleur | Shimano CUES U6000 GS |
| Crank | Prowheel alloy, 40T narrow-wide ring, 170mm length |
| Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10 speed |
| Chain | Shimano LG500, 9/10/11 speed |
| Brake | Shimano hydraulic disc, MT201 lever, UR300 caliper // Shimano hydraulic disc, MT201 lever, UR300 caliper |
| Brake Rotor | Shimano RT26, 6-bolt, 160mm |
| Pedal | Wellgo nylon body, alloy cage |
| Saddle | Verse Short, chromoly rails, 145mm width |
| Seatpost | Bontrager alloy, 27.2mm, 12mm offset, 330mm length |
| Handlebar | Bontrager Comp Lowriser, alloy, 31.8mm, 15mm rise, 600mm width |
| Stem | Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length |
| Grips | Trek Line Comp, nylon lock-on |
Geometry Chart
| B B Drop | 6.5 |
| B B Height | 28.5 |
| Chainstay Length | 44.7 |
| Eff Top Tube | 52.8 |
| Frame Reach | 38.3 |
| Frame Size Letter | XS |
| Frame Size Number | 40 |
| Frame Stack | 54.3 |
| Head Angle | 70.0° |
| Head Tube Length | 11.5 |
| Offset | 5 |
| Seat Tube | 33 |
| Seat Tube Angle | 75.0° |
| Standover | 67.5 |
| Trail | 7.4 |
| Wheelbase | 105.2 |
| Wheel Size | 700c |
