Product Description
Ride-it-all suspension
55mm rear travel and a new 60mm Rudy XL suspension fork designed in collaboration with RockShox help smooth out rough gravel roads and let you venture onto singletrack with more comfort and capability than a rigid gravel bike.
The ultimate off-road drop bar
A new GR CheckOUT gravel drop bar has multiple hand positionings for more comfort and efficiencey wherever your ride takes you. Settle into narrow tops for more speed on champagne gravel or reach for the extra wide drops for total control on the rough stuff.
The science of full suspension gravel
CheckOUT's full suspension setup is proven to decrease fatigue and increase comfort and control when compared to its rigid counterparts, leading to a 7.3% reduction in rider ventilation, a 41.5% reduction in fatiguing vibrational energy, and 23% less steering variation.
Big ol' tire clearance
Room for tires up to 56mm/2.2″ wide lets you tackle the rough stuff with confidence.
Geometry designed to keep you in control
Get more stability and comfort on multi-surface, multi-day adventures with an all-new Gravel Adventure geometry designed with a longer reach and higher stack.
Built for bikepacking
Haul it all with 18* frame mounts, an integrated rear rack that works with the bike's suspension and dropper post, and Adjustable Multi-Mounts that lets you position your bottles and gear exactly where you want 'em in the frame.*Sizes ML and up
| Frame | 500 Series OCLV Carbon, integrated frame bag mounts, integrated rack, T47, UDH, 142x12mm chamfered thru axle, 55mm travel |
| Fork | RockShox Rudy XL Ultimate, Charger Race Day 2 Solo Air spring, tapered steerer, 45mm offset, 12x100mm thru axle, 60mm travel |
| Shock | RockShox SIDluxe Ultimate 3P, 170mmx27.5mm |
| Wheel Front | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle |
| Wheel Rear | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, Shimano Micro Spline freehub, 142x12 thru axle |
| Tire | Bontrager Betasso RSL GX, Tubeless ready, aramid bead, 60 tpi, 700x55mm |
| Tire Part | Bontrager TLR sealant, 6oz |
| Rim Strip | Bontrager TLR |
| Skewer Rear | Bontrager Switch chamfered thru axle, removable lever |
| Shifter | Shimano GRX RX820, 12 speed // Shimano GRX RX820, 12 speed |
| Rear Derailleur | Shimano GRX RX822, 51T max cog |
| Crank | Shimano GRX RX610, 38T, 160mm length |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Cassette | Shimano XT M8200, 10-51, 12 speed |
| Chain | Shimano Ultegra/XT M8100 |
| Brake Rotor | Shimano CL800, centerlock, 160mm |
| Saddle | Verse Short Comp, steel rails, 145mm width |
| Seatpost | TranzX JD-YSI36, 100mm travel, internal routing, 31.6mm, 328mm length |
| Handlebar | Bontrager GR Checkout, 42cm |
| Stem | Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length |
| Cargo Rack | Checkout rear rack |
Geometry Chart
| B B Drop | 7 |
| Chainstay Length | 44.2 |
| Eff Top Tube | 56.4 |
| Frame Reach | 39.5 |
| Frame Size Letter | S |
| Frame Stack | 58 |
| Head Angle | 68.8° |
| Head Tube Length | 8.3 |
| Offset | 4.8 |
| Seat Tube | 44 |
| Seat Tube Angle | 74.6° |
| Standover | 77.2 |
| Trail | 9.2 |
| Wheelbase | 108.1 |
| Wheel Size | 700c |
