Product Description
by Online Instructor (Author)
Solid Edge 2022 Basics and Beyond provides the student or practicing engineer with a basic introduction to 3D modeling using Solid Edge 2022. The topics are laid out in step-by-step format with examples and exercises at the end of each chapter to practice the concepts covered. The author uses numerous computer screenshots to explain software features.
Solid Edge is different from other Computer Aided Designing software. It offers a rich set of tools known as Synchronous Modeling tools, which help you to create and edit design concepts very quickly and easily. Also, it helps you to design models keeping in mind the final design intent. However, you are required to know the rules of this software to avoid any errors. This book will be helpful if you are beginning to learn Solid Edge.
Table of Contents
1. Getting Started with Solid Edge 2022
2. Sketch Techniques
3. Extrude and Revolve Features
4. Placed Features
5. Patterned Geometry
6. Sweep Features
7. Loft Features
8. Additional Features and Multibody Parts
9. Modifying Parts
10. Assemblies
11. Drawings
12. Sheet Metal Design
13. Surface Design
14. Subdivision modeling
