Product Description
Sol-Ark 30K-3P Hybrid Inverter | 120/208V 3-Phase Output | Scalable Backup Power for Light Commercial Operations
With native 120/208V three-phase output and transformerless design, Sol-Ark 30K-3P-208V commercial hybrid inverter eliminates costly step-down transformers while delivering professional-grade performance for offices, retail spaces, warehouses, and small manufacturing facilities seeking energy independence.
- Native 120/208V 3-Phase Output
- 39kW Solar Input Capacity
- AC/DC Coupling Flexibility
About the Product
The Sol-Ark 30K-3P-208V three-phase hybrid inverter delivers 30,000W continuous AC power with four independent MPPT trackers supporting up to 39kW of solar array capacity. This commercial solar inverter features dual coupling architecture, enabling both DC-coupled new installations and AC-coupled retrofits of existing grid-tied PV systems without equipment replacement.
Built for commercial resilience, the 200A grid pass-through relay maintains power to every circuit during outages, while the 20ms (adjustable) transfer time ensures uninterrupted operation for sensitive equipment and point-of-sale systems. The NEMA 3R weatherproof enclosure operates from -40°F to 140°F, making this battery-ready inverter suitable for rooftop and outdoor installations across all climates.
System scalability reaches 300kW with parallel stacking of up to 10 inverters, while dual battery inputs support 160-500V lithium systems with CAN bus communication. The French cleat mounting system simplifies installation, while Wi-Fi and Ethernet connectivity enables real-time monitoring through the MySolArk platform.
Specifications
|
Type |
Hybrid |
|
AC Output Power |
30,000W continuous (45,000VA peak for 10s) |
|
Phases |
3-phase 120/208V |
|
Efficiency |
97.5% max / 96.5% CEC weighted |
|
DC Input Voltage |
150-500V MPPT range / 180V startup / 550V max |
|
MPPT Trackers |
4 independent trackers (2 strings per tracker) |
|
AC Output Voltage |
120/208V three-phase |
|
Battery Support |
Lithium-ion (160-500V / 50-9900Ah) - 2 inputs |
|
Protections |
UL 1741SB, AFCI, rapid shutdown, ground fault, Type II/III surge |
|
Operating Conditions |
-40°F to 140°F (>113°F derating) / IP65 (NEMA 3R) |
|
Warranty |
10 years (manufacturer standard) |
