Product Description
- The stepthrough frame makes it easy to hop on and go, and hop off when your ride is over
- The cables are routed internally, which protects them from the elements and adds to the bike's sleek look
- It's easy to accessorize with racks, a kickstand, fenders, lights, and more!
- Like every Trek hybrid, it's backed by a lifetime warranty and supported by a wide network of retail partners
A better way to produce aluminum
Starting in 2024, we began removing high-emission aluminum from our manufacturing and replacing it with low-emission aluminum made with renewable energy. By October 2025, nearly every alloy bike we make - this one included - had made the switch, driving a major drop in our footprint.
Shimano CUES
Inspired by rider demand for trouble-free drivetrain longevity and performance, Shimano CUES offers a new foundation for versatility and durability across a range of both electric and standard bikes. CUES features Shimano’s new LINKGLIDE drivetrain technology for significantly increased life on wear items like chain, cassette, and chainrings.
Shimano LINKGLIDE
LINKGLIDE technology has been specifically engineered for incredible durability while still delivering smooth and decisive shifting – along with a great pedalling experience. Available exclusively on Shimano CUES drivetrains.
Upgrade your pedals and love your bike more
Pedals are two of the five touchpoints that connect you with your bike, and even though this bike comes with a pair, upgrading to pedals that boost control and grip will greatly improve your ride. See the pedal guide and find the best pedals for your riding style. We recommend flat pedals for simple versatility.
| Frame | Alpha Gold Aluminum, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR |
| Fork | FX alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR |
| Tire | Bontrager H2 Comp, wire bead, 30 tpi, 700x35mm |
| Hub Front | Formula DC-20, alloy, 6-bolt, 100x5mm |
| Hub Rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm |
| Rim | Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve |
| Skewer Front | 139x5mm bolt-on |
| Skewer Rear | 152x5mm QR |
| Shifter | Shimano U4000, 9 speed |
| Rear Derailleur | Shimano CUES U4000 |
| Crank | ProWheel Pro alloy, 40T narrow-wide steel ring, 170mm length |
| Bottom Bracket | Sealed cartridge, 68mm |
| Cassette | Shimano LINKGLIDE LG300, 11-46, 9 speed |
| Brake Rotor | Tektro wave, 6-bolt, 160mm |
| Pedal | Bontrager City pedals |
| Saddle | Bontrager Sport |
| Seatpost | Bontrager alloy, 27.2mm, 12mm offset, 400mm length |
| Handlebar | Bontrager alloy, 31.8mm, 15mm rise, 660mm width |
| Stem | Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 100mm length |
Geometry Chart
| B B Drop | 6.5 |
| B B Height | 28.5 |
| Chainstay Length | 44.7 |
| Eff Top Tube | 61.3 |
| Frame Reach | 40.9 |
| Frame Size Letter | XL |
| Frame Size Number | 60 |
| Frame Stack | 64.8 |
| Head Angle | 72.5° |
| Head Tube Length | 21.5 |
| Offset | 5 |
| Seat Tube | 52 |
| Seat Tube Angle | 72.5° |
| Standover | 83.6 |
| Trail | 5.8 |
| Wheelbase | 108.7 |
| Wheel Size | 700c |
