Product Description
Three AMD Ryzen Configs. Dual M.2 Storage. Wi-Fi 6. HDMI 2.0 + DP 1.4. Under 35dB. VESA Included.
The Firebat R3 is a compact desktop mini PC available with three AMD Ryzen processor options: the Ryzen 7 7730U (8-core, 16-thread, up to 4.5GHz, CINEBENCH R23: ~10792), the Ryzen 5 7430U, or the Ryzen 3 4300U. All configurations run AMD Radeon integrated graphics and ship with LPDDR4 onboard RAM (soldered - not user-replaceable). Dual M.2 slots (one SATA + one NVMe) support up to 2TB total storage expansion. Connectivity: Wi-Fi 6, Bluetooth 5.2, Gigabit LAN, HDMI 2.0, DisplayPort 1.4, and a full front + rear port layout with no dongles needed. Noise under 35dB at full load. Includes VESA mount, HDMI cable, 65W adapter, and user manual. Windows 11 pre-installed. CE + FCC certified. Ships from United States.
Important: The RAM is onboard LPDDR4 and is soldered to the motherboard. It cannot be removed, replaced, or upgraded by the customer. Do not attempt to modify the RAM.
Key Features
- AMD Ryzen 7 7730U - 8-core, 16-thread, up to 4.5GHz boost - The flagship R3 configuration; 8 cores and 16 threads with 16MB L3 cache and 4.5GHz max boost clock; CINEBENCH R23 multi-core score of approximately 10,792 in factory testing; outperforms Ryzen 5 3500U and Intel N150 by a significant margin; suited for demanding office workloads, content creation, multi-window multitasking, and light video editing
- AMD Ryzen 5 7430U and Ryzen 3 4300U options - Ryzen 5 7430U offers strong mid-range performance for everyday productivity, office, and media; Ryzen 3 4300U is the entry configuration for general home computing, web browsing, and office tasks at a lower price point
- LPDDR4 RAM - onboard soldered (not upgradeable) - Low-power DDR4 for efficient, silent operation; 8GB config for light use; 16GB config for multitasking and heavier workloads; RAM is permanently soldered to the board and cannot be upgraded after purchase - select your RAM tier carefully
- Dual M.2 slots - SATA + NVMe, up to 2TB total - Ships with one M.2 SSD installed; the second M.2 slot is empty and available for user storage expansion; SATA slot for standard M.2 SATA SSDs; NVMe slot for faster PCIe NVMe drives; total expandable capacity up to 2TB
- AMD Radeon integrated graphics - Handles 4K video playback, dual-monitor output, light photo editing, and casual non-GPU-intensive tasks; no discrete GPU
- Wi-Fi 6 (802.11ax) + Bluetooth 5.2 - Wi-Fi 6 for faster wireless throughput and better performance in congested networks; BT 5.2 for wireless peripherals, headphones, and accessories
- Gigabit LAN (1000Mbps) - Wired Ethernet for stable, low-latency connectivity; ideal for business and office environments where reliable network performance is required
- HDMI 2.0 + DisplayPort 1.4 - dual monitor output - Connect two displays simultaneously; HDMI 2.0 supports up to 4K@60Hz; DP 1.4 supports up to 4K@120Hz or 8K@60Hz; ideal for dual-monitor productivity workstations
- Full port layout - no dongles required - Front: USB-C, 2×USB-A 3.2 Gen 2, audio jack; Rear: 4×USB-A 3.0, HDMI 2.0, DP 1.4, Gigabit LAN, DC power; 8 USB ports total plus video and audio - connects keyboards, mice, monitors, printers, external drives, and headsets without adapters
- Under 35dB at full load - near-silent operation - Active cooling tuned to stay below 35dB even under sustained CPU load; suitable for quiet home offices, bedrooms, classrooms, and library environments
- VESA mount included - Mount the R3 directly to the back of a VESA-compatible monitor or TV; eliminates desk footprint entirely; ideal for clean, space-saving setups
- In the box: R3 Mini PC, 65W power adapter, VESA mount, HDMI cable, user manual
- Windows 11 pre-installed
- CE + FCC certified
- Ships from United States
Processor Comparison
- Ryzen 7 7730U - 8-core, 16-thread, up to 4.5GHz, CB R23 ~10,792: Best performance; suited for content creation, video editing, heavy multitasking, developer workloads, and future-proofing; recommended if budget allows
- Ryzen 5 7430U: Mid-range; strong for everyday productivity, office, media, and moderate multitasking; best value for most home and office users
- Ryzen 3 4300U: Entry-level; web browsing, email, Microsoft Office, streaming, and general home computing; recommended for light users on a tighter budget
Specifications
- Brand: Firebat
- Model: R3
- Processor Options: AMD Ryzen 7 7730U (8C/16T, 4.5GHz boost) | AMD Ryzen 5 7430U | AMD Ryzen 3 4300U
- Graphics: AMD Radeon Integrated Graphics
- RAM: LPDDR4, onboard soldered (8GB or 16GB - not upgradeable)
- Storage Configs: 8GB RAM + 256GB SSD | 16GB RAM + 512GB SSD
- Storage Slots: 2×M.2 (1×SATA + 1×NVMe), up to 2TB total
- Wi-Fi: Wi-Fi 6 (802.11ax)
- Bluetooth: 5.2
- LAN: Gigabit Ethernet (1000Mbps)
- Video Output: HDMI 2.0 + DisplayPort 1.4
- Front Ports: USB-C, 2×USB-A 3.2 Gen 2, 3.5mm audio
- Rear Ports: 4×USB-A 3.0, HDMI 2.0, DP 1.4, Gigabit LAN, DC power
- Operating System: Windows 11
- Noise: <35dB at full load
- Power Adapter: 65W
- Color: Black
- Weight: 1.05kg
- Certification: CE, FCC
- In the Box: R3 Mini PC, 65W adapter, VESA mount, HDMI cable, user manual
- Ships From: United States
Frequently Asked Questions
Can the RAM be upgraded after purchase?
No - the RAM is LPDDR4 soldered directly to the motherboard and cannot be removed, replaced, or upgraded by the customer or a third-party technician without risking permanent damage to the board. This is a fundamental hardware characteristic of the R3, not a warranty restriction. LPDDR4 soldered RAM is standard on mini PCs in this form factor because it allows a smaller PCB, lower power consumption, and better signal integrity compared to socketed RAM. You must select the correct RAM tier at the time of purchase: 8GB for light single-user computing or 16GB for multitasking, content creation, and heavier workloads. If you anticipate needing more than 16GB of RAM in the future, this product is not the right choice.
How many monitors can the R3 support and at what resolution?
The Firebat R3 supports dual monitor output simultaneously via HDMI 2.0 and DisplayPort 1.4. HDMI 2.0 supports up to 4K (3840×2160) at 60Hz. DisplayPort 1.4 supports up to 4K at 120Hz or 8K at 60Hz. You can run two 4K monitors simultaneously - one on HDMI and one on DP - for a high-resolution dual-monitor productivity workstation. Note that dual 4K output at high refresh rates requires GPU bandwidth from the AMD Radeon integrated graphics, which is shared with system RAM. For the best dual-monitor experience, use the 16GB RAM configuration to ensure adequate memory bandwidth for both displays plus active applications.
What is the second M.2 slot and how do I add more storage?
The R3 ships with one M.2 SSD installed in the primary slot (256GB or 512GB depending on your configuration). The second M.2 slot is empty and physically accessible inside the unit for user storage expansion. It supports standard M.2 2280 form factor drives. One slot is SATA and one is NVMe - verify which slot is which in the Firebat R3 documentation before purchasing an expansion drive to ensure compatibility. For maximum speed, install an NVMe PCIe SSD in the NVMe slot. SATA M.2 SSDs are slower but more affordable and work in the SATA slot. Total expandable storage capacity is up to 2TB across both slots. Adding a second drive does not require reinstalling Windows - the new drive appears as an additional volume in Windows Disk Management.
How does the Ryzen 7 7730U compare to entry-level Intel mini PC processors?
The AMD Ryzen 7 7730U with 8 cores, 16 threads, and a 4.5GHz boost clock significantly outperforms common entry-level Intel mini PC processors in multi-threaded workloads. The CINEBENCH R23 multi-core score of approximately 10,792 (factory tested) places it well above Intel N100, N150, N200, and similar low-power Intel N-series chips commonly found in budget mini PCs (which typically score 2,000-4,500 in multi-core). For single-threaded tasks (web browsing, office), the gap narrows, but for sustained multi-core work - video encoding, compiling, running multiple applications simultaneously - the 7730U's 8 cores provide a categorical performance advantage. If you're comparing the R3 to a mini PC with an Intel N100 or N150, the Ryzen 7 7730U configuration offers substantially more headroom for demanding workloads.
Is the R3 suitable as a home theater PC (HTPC) or living room media center?
Yes - the Firebat R3 is well-suited for HTPC use. The HDMI 2.0 output connects directly to a 4K TV; AMD Radeon integrated graphics handles hardware-accelerated 4K video playback (H.264, H.265/HEVC, AV1) efficiently without encoding or frame drops. The under-35dB noise level means the fan is inaudible from normal viewing distances in a living room environment. The VESA mount allows the R3 to be mounted directly behind a VESA-compatible TV, completely hiding it from view. Bluetooth 5.2 pairs with wireless keyboards, mice, and remote controls. The Ryzen 3 4300U or Ryzen 5 7430U configurations are sufficient for pure HTPC use - the Ryzen 7 7730U is recommended only if you also plan to use it as a productivity workstation alongside media center duties.
Does the R3 come with Windows 11 and is it a full license?
Yes - the Firebat R3 ships with Windows 11 pre-installed. This is a full OEM Windows 11 license tied to the device's hardware, which means it activates automatically when connected to the internet and does not require a separate product key entry. It is compatible with all standard Windows software including Microsoft Office (purchased separately or via Microsoft 365), browsers, productivity tools, and developer applications. Windows 11 Home is the standard edition for consumer mini PCs in this category. The system language can be changed in Windows Settings if you prefer a language other than the default. Note that some Windows 11 features (e.g., TPM 2.0-dependent security features) depend on hardware support - verify specific feature requirements with Firebat if these are critical to your use case.
