Product Description
Product information:
1/2.7”5Megapixel progressive CMOS
Max. Resolution：2592 (H) × 1944 (V)
ROM：128 MB
RAM：512 MB
Scanning System：Progressive
Electronic Shutter Speed：Auto/Manual 1/3 s–1/100,000 s
Min. Illumination:0.003 Lux @ F1.0
S/N Ratio:> 56 dB
Illumination Distance:30 m (98.4 ft)
Illuminator On/Off Control:Auto/Manual
Illuminator Number:1 (Warm light)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+/Smart H.264+
Main stream: 2592 × 1944 @1-20 fps
2688 × 1520 @1-25/30 fps
Sub stream: 704 × 576 @1-25 fps/704 × 480 @ 1-20fps
Third stream: 1920 × 1080 @1-25/30 fps
Stream Capability:3 streams
Resolution:5M (2592 × 1944); 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (354 × 288/354 × 240)
Bit Rate Control:CBR/VBR
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night:Color/B/W
BLC:Yes
HLC:Yes
WDR:120 dB
Scene Self-adaptation (SSA):Yes
Packing list:
IP camera*1
