Encyclopedia of Electronic Circuits, Volume 7 - Paperback

by Rudolf F. Graf (Author), William Sheets (Author)

Publisher's Note: Products purchased from Third Party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.

Back Jacket

Publisher's Note: Products purchased from Third Party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.
An extensive library of 1,000 circuits from the bestselling, seven-volume Encyclopedia of Electronic Circuits

Praise for previous volumes:

"A virtual treasurehouse...an invaluable reference tool for every hobbyist, technician, student, and design professional." -- Electronics For You

"...a ready source to which to turn for just about any type of circuit you can imagine..." -- Modern Electronics

NEW IN THE BESTSELLING SERIES! ONE THOUSAND MORE LEADING-EDGE CIRCUIT DESIGNS!

Designed for quick reference and on-the-job use, the Encyclopedia of Electronic Circuits, Volume 7, puts over 1000 state-of-the-art electronic and integrated circuit designs at your fingertips. Organized alphabetically by circuit type, this all-new collection includes the latest designs from industry giants such as Advanced Micro Devices, Motorola, Teledyne, General Electric, and others.

For each circuit, you'll find a brief explanation of its operation and other information regarding adjustments or alignment. An invaluable reference tool, this book also includes a cumulative index that covers all the circuits here and in each of the previous 6 volumes.

Inside you'll find diagrams and schematics for circuits used in:
* Power supplies
* Computers
* Amplifiers
* Sine wave oscillators
* Flow detectors
* Filters
* Frequency meters
* Infrared devices
* Games
* Phase detectors
* Optically coupled devices
* Generators
* Microwave receivers
* Signal injectors
* Time delay apparatuses
* Laser tools
* Probes
* And many other applications!

Author Biography

Rudolf F. Graf has 45 years of engineering, sales, and marketing experience in the electronics field. He has written more than 30 books (about three million copies printed)and well over 100 articles. He is a senior member of the IEEE, a licensed amateur radio operator (KA2CWL), and has a BSEE degree from Polytechnic Institute of Brooklyn and an MBA from NYU. He is self-employed.

William Sheets is a self-employed circuit design engineer. He has more than 25 years of experience in RF, analog, and digital electronics. He has written numerous articles in electronics publications and co-authored five books with Graf. His interests include amateur radio (K2MQJ), photography, and travel. He has designed and built numerous items, including a satellite TV system, many transmitters and receivers, and a computer. He has an MEE degree from NYU, is married, and lives in up-state New York.
