Product Description
by Ascent - Center for Technical Knowledge (Author)
The Creo Parametric 6.0: Design Documentation and Detailing learning guide is designed for all draftspersons that document designs using Creo Parametric. It focuses on how to use Creo Parametric to communicate design information from your part and assembly models.
Topics Covered
- View creation
- View manipulation
- Detailing a drawing
- Drawing notes
- Tolerances
- Assembly drawings
- Drawing tables
- 2D sketching
- Symbols
Prerequisites
- Access to the Creo Parametric 6.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
- Completing Creo Parametric 6.0: Introduction to Solid Modeling or equivalent Creo Parametric 6.0 experience.
Number of Pages: 588
Dimensions: 1.19 x 9.25 x 7.5 IN
Publication Date: September 18, 2020
