Product Description
by Ascent -. Center for Technical Knowledge (Author)
The CATIA V5-6R2018: Functional Tolerancing & Annotation learning guide is extensive hands-on course with numerous practices that helps you acquire the skills to create and display engineering, manufacturing, and assembly information directly on the 3D part, assembly, or process model. Students attending this course will receive a thorough understanding of geometric tolerances, dimensions, notes, and other annotations critical to the accurate and cost-effective creation of mechanical parts and assemblies. The 3D Functional Tolerancing and Annotation course complies with the industry and government initiated American Society of Mechanical Engineers' (ASME) Y14.41 3D standards for the creation and submission of model only, paperless design applications.
Topics Covered
- Introduction to Functional Tolerancing & Annotation
- Workbench overview
- Annotation process
- Extracting 2D view from the 3D model
- Annotation planes and extraction views
- Construction geometry
- Semantic and non-semantic annotations
- Datum Reference Frames
- Tolerance Advisor
- Basic Dimensions
- Annotations: Text, Flag Notes, Datum Elements, Datum Targets, Roughness, Dimensions
- Restricted Areas
- Threads
- Annotation Visualization Tools: Query, Grouping, Leader Symbols, Annotation Mirror and Transfer, Filters
- Cameras and Captures
- Geometry Connection Management
- FT&A analysis and reporting
- Product Functional Tolerance and Annotation workbench
Prerequisites
- CATIA V5-6R2018: Introduction to Modeling and working knowledge of GD&T application.
