Product Description
by Tutorial Books (Author)
CATIA V5-6R2017 Basics introduces you to the CATIA V5 user interface, basic tools and modeling techniques. It gives users a strong foundation of CATIA V5 and covers the creation of parts, assemblies, drawings, sheetmetal parts, and complex shapes. This textbook helps you to know the use of various tools and commands of CATIA V5 as well as learn the design techniques. Every topic of this textbook starts with a brief explanation followed by a step by step procedure. In addition to that, there are tutorials, exercises, and self-test questionnaires at the end of each chapter. These ensure that the user gains practical knowledge of each chapter before moving on to more advanced chapters.
Table of Contents
1. Getting Started with CATIA V5-6R2017
2. Sketcher Workbench
3. Basic Sketch Based Features
4. Holes and Dress-Up Features
5. Patterned Geometry
6. Rib Features
7. Multi Section Solids
8. Additional Features and Multibody Parts
9. Modifying Parts
10. Assemblies
11. Drawings
12. Sheet Metal Design
13. Surface Design
If you are an educator, you can request an evaluation copy by sending us an email to online.books999@gmail.com
