Product Description
- Electric bikes amplify your power so you can enjoy the best parts of riding even more
- The lowstep geometry gives you more confidence when mounting and dismounting
- The hub drive motor and 250Wh battery give you just enough push without going overboard
- Its 27.5" wheels are super stable and maneuverable, and 2" tires boost cushion and grip for a smoother ride
- A Hyena LED controller makes changing between ride modes seamless and easy
Powerful drive system
A lightweight and powerful 40Nm rear hub drive offers confident handling and uninterrupted power.
Light and comfortable
The updated frame keeps your ride light, easy to handle, and easy to store when you're done – all the while elevating comfort so you can spend more time enjoying the ride.
A better way to produce aluminum
Starting in 2024, we began removing high-emission aluminum from our manufacturing and replacing it with low-emission aluminum made with renewable energy. By October 2025, nearly every alloy bike we make - this one included - had made the switch, driving a major drop in our footprint.
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification — so all you have to worry about is where your e-bike will take you next.
Upgrade your pedals and love your bike more
Pedals are two of the five touchpoints that connect you with your bike, and even though this bike comes with a pair, upgrading to pedals that boost control and grip will greatly improve your ride. See the pedal guide and find the best pedals for your riding style. We recommend flat pedals for simple versatility.
| Frame | Alpha Gold Aluminum, lowstep, internal cable routing, internal battery, rack & fender mounts, post mount disc, kickstand mount, 144.5mm OLD hub motor spacing |
| Fork | Verve+ LT alloy, threadless steel steerer, ThruSkew QR |
| Tire | Bontrager H2 Comp, wire bead, 30 tpi, 27.5x2.00'' |
| Hub Front | Formula DC-20, alloy, 6-bolt, 100x5mm |
| Hub Rear | Hyena hub drive motor, 40Nm, 250W |
| Rim | Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve |
| Skewer Front | 132x5mm QR, ThruSkew |
| Shifter | Shimano M315, 8 speed |
| Rear Derailleur | Shimano Acera M3020-8, 40T max cog |
| Crank | ProWheel Pro alloy, 42T narrow-wide steel ring, 170mm length |
| Bottom Bracket | Torque sensor, threaded, 122.5mm spindle |
| Cassette | Shimano HG20, 12-32, 8 speed |
| Chain | KMC Z8.3 |
| Brake | Tektro HD-M275 hydraulic disc // Tektro HD-M275 hydraulic disc |
| Brake Rotor | Tektro wave, 6-bolt, 160mm // Tektro, 6-bolt, 160mm |
| Pedal | Bontrager City pedals |
| Saddle | Bontrager Boulevard |
| Seatpost | Bontrager alloy, 31.6mm, 12mm offset, 330mm length |
| Handlebar | Bar/stem w/ light mount |
| Stem | Integrated stem, 35mm clamp |
| Grips | Bontrager Satellite |
| Fender | SKS wide // SKS wide, plastic |
| Cargo Rack | MIK-compatible alloy rear rack |
| Light | Herrmans MR5-E, 140lumen, 40lux, LED, headlight // Spanninga Solo, taillight |
| Kickstand | Adjustable length alloy kickstand |
| Battery | 250Wh, integrated in down tube |
| Charger | 2A, 42V output, 100V-240V AC input |
Geometry Chart
| B B Drop | 6 |
| B B Height | 28.9 |
| Chainstay Length | 48.7 |
| Eff Top Tube | 57.1 |
| Frame Reach | 37 |
| Frame Size Letter | S |
| Frame Stack | 61.8 |
| Head Angle | 69.0° |
| Head Tube Length | 15 |
| Offset | 4.6 |
| Seat Tube | 38 |
| Seat Tube Angle | 72.0° |
| Standover | 41 |
| Trail | 8.5 |
| Wheelbase | 111.7 |
| Wheel Size | 700c |
